UTS2255 Operating Demo — How the Drum Separates

Working footage of the UPSEN UTS2255 tracked trommel screen: an 80-300 t/h tracked trommel screen on b400x4100mm built for compost Soil. This page is the dedicated watch page for this video — the full machine specification and enquiry form are on the UTS2255 product page.

Machine
UTS2255 Tracked Trommel Screen
Video length
6 min 18 sec
Published
22 September 2026
Video file
f6b0284cd3c98eb5a0dac17fb00c3318.mp4

About this video

An operating demonstration of the UTS2255 with the drum empty, which is the clearest way to see how a trommel actually separates.

The drum turns slowly and material inside it rides up the wall, falls back on itself, and in doing so presents new faces to the apertures. Anything smaller than the aperture drops through; anything larger travels the length of the drum to the oversize end. That is the whole mechanism, and it is why a trommel does not blind on damp or fibrous feed the way a flat deck does — the material is continuously turning over rather than lying on a mesh.

The apertures are the setting that matters. Changing them changes the product, not the machine's capacity, and on a trommel that change is often a matter of swapping drum sections or panels rather than an adjustment.

The feed conveyor and the two discharge belts are shown running. The B1000 feed belt into a 2200×5000 mm hopper is deliberately wider than the drum can classify, so the hopper can be charged by a loader without the operator waiting on the drum.

No material is fed here; throughput appears in the working video of this model.

For buyers comparing options: this machine appears in 2 other working videos on this site — see the links below. The full specification table and EU conformity documentation are on the UTS2255 product page.

Prices are quoted per project rather than published as a fixed figure, because the final price varies significantly with the diesel engine specified (brand, power rating and emission standard), the machine configuration (chassis, screening decks, conveyors, CE or EPA compliance), the drive mode (tracked or wheeled, and how the crusher itself is driven), and exchange-rate movement at the time of order.

Send your throughput, feed material, site conditions and destination port through the enquiry form, and we will reply with a configuration and an itemised quotation.

UTS2255 key specifications

Hopper Size
2200x5000mm
Feed Conveyor
B1000x3500mm
Roller Diameter
2200mm
Roller Length
5500mm
Screen Mesh
10mm (customizable)
Discharge Conveyors
B800x4500mm + B1000x4500mm
Track Type
B400x4100mm
Screen Cleaner
Φ450
Engine
91KW/125HP
Capacity
80-300 t/h
Total Weight
25,000 kg
Transport Size
11500x3700x4100mm

Where the UTS2255 is used

Typical applications

  • Compost, topsoil and green waste screening
  • C&D fines recovery
  • Sand and gravel washing feed preparation
  • Biomass and wood chip sizing

Raw materials handled

  • Crushed stone and aggregate
  • Sand and gravel
  • Topsoil and overburden
  • C&D fines and screened rubble

Common questions about the UTS2255

What does video 2 of the UTS2255 show?

This clip runs 6 min 18 sec. It is working video 2 of 3 published for the UTS2255, and shows the machine in its working configuration. The full specification and enquiry form are on the UTS2255 product page.

How much does a UTS2255 weigh?

The UTS2255 has an operating weight of 25,000 kg.

What materials can the UTS2255 handle?

The UTS2255 is used with crushed stone and aggregate; sand and gravel; topsoil and overburden; c&D fines and screened rubble. See the UTS2255 product page for the full specification.

Does the UTS2255 come with EU conformity documentation?

The UTS2255 is supplied with EU conformity documentation; the delivery route is confirmed with your order.
