UZS1340 Walkaround — Deck, Frame and Conveyors
Working footage of the UPSEN UZS1340 tracked mobile screening plant: a 120–300 t/h tracked mobile screening plant on b400x4200mm built for aggregate Topsoil. This page is the dedicated watch page for this video — the full machine specification and enquiry form are on the UZS1340 product page.
About this video
A structural walkaround of the UZS1340 with the deck empty.
The screening deck and its frame are the subject of the first half. On a 21,500 kg scalper, the deck frame carries the screen media, the material and the vibration, which makes it the most heavily loaded structure on the machine. The clip shows the side plates, the cross members and the mounting of the vibrator unit — the parts that determine whether a screen runs smoothly for years or cracks welds in months.
The feed section follows. This machine takes unclassified site material, so the hopper is built to survive a loader bucket rather than to meter material precisely, and the wear liners in it are consumables.
The discharge conveyors close the walkaround. On a scalper there are usually two products — fines through the deck and oversize off the end — and on a tracked plant both have to be positioned so the stockpiles build where the operator wants them.
Seventy-five to one hundred and ninety cubic metres an hour is a volume rating; the tonnage depends entirely on what the material weighs.
For buyers comparing options: this machine appears in 1 other working video on this site — see the links below. The full specification table and EU conformity documentation are on the UZS1340 product page.
Send your throughput, feed material, site conditions and destination port through the enquiry form, and we will reply with a configuration and an itemised quotation.
UZS1340 key specifications
Where the UZS1340 is used
Typical applications
- Scalping sticky, wet or high-fines feed
- Pre-screening before a crusher
- Road base and armour rock grading
- Heavy-duty topsoil and overburden separation
Raw materials handled
- Crushed stone and aggregate
- Sand and gravel
- Topsoil and overburden
- C&D fines and screened rubble
Common questions about the UZS1340
What does video 1 of the UZS1340 show?
This clip runs 33 sec. It is working video 1 of 2 published for the UZS1340, and shows the machine in its working configuration. The full specification and enquiry form are on the UZS1340 product page.
What is the capacity of the UZS1340?
The UZS1340 is rated at 120-300 t/h. Achieved output depends on the feed material, its moisture content and how the machine is set up.
How much does a UZS1340 weigh?
The UZS1340 has an operating weight of 21,500 kg.
What materials can the UZS1340 handle?
The UZS1340 is used with crushed stone and aggregate; sand and gravel; topsoil and overburden; c&D fines and screened rubble. See the UZS1340 product page for the full specification.
More videos of this machine
More mobile screener working videos
Get a price for the UZS1340
Tell us your feed material, required output and site conditions — we will reply with a configuration and quotation. The UZS1340 is available for sale worldwide, and EU conformity documentation is supplied with every unit.
